Sightmark Core HX 3-12x56 HDR Hunter Dot Riflescope

$314.97

Designed to tackle all the obstacles faced by the modern rifle hunter, the Sightmark Core HX 3-12x56 HDR Riflescope has been crafted to offer versatility in the field and excel in low-light conditions. This reliable 3-12 magnification riflescope is equipped with a 56mm objective lens for enhanced low-light performance and a dot duplex reticle for precision shot placement. This reliable optic was crafted to accompany a variety of hunting rifle calibers. The Core HX 3-12x56 HDR Hunter Dot is constructed from a single piece of durable aircraft-grade aluminum to withstand the most punishing conditions and is shockproof, fogproof, and waterproof.

Be the first to review this product

Product Description

Included in Package

Neoprene scope cover
30mm scope rings

Product Downloads

Specifications

Length (in/mm)	12.72/323
Width (in/mm)	2.56/65
Height (in/mm)	1.87/47.5
Weight, oz	25
Reticle, Type	HDR-Hunter Dot Reticle
Reticle	etched
Reticle, Color	red
Illuminated (yes/no)	yes
Reticle Brightness Setting	0-11
Finish/Color	Matte black
Magnification	3-12
Diameter, Objective Lens	56 mm
Diameter, Eyepiece	1.65/42 mm
Diameter, Exit Pupil	14.6-5 mm
Eye relief (in/mm)	4.3-3.8/109.2-96.5
Field of view, m@100m	11.83-2.93
Field of view, ft@100yd	35.5-8.8
Diopter Adjustment	+2 to -2 (+/-)
Diameter, Tube	1.18/30 in/mm
Parallax Setting	20- ∞ yards
Windage Range of Adjustment	60 MOA
Elevation Range of Adjustment	60 MOA
Windage & Elevation, Lock	no yes/no
Adjustment Value	1/4 MOA (one click=)
Maximum Recoil	.416 Rem
Sunshade	No yes/no
Nitrogen Filled	yes yes/no
Shockproof	yes yes/no
Fog Proof	yes yes/no
Focal Plane	2nd
IP Standard	IP67-waterproof to 1m/3ft for 1 hour water rating
Body Material	Aluminum
Material, Lens	glass type
Lens Coating	Fully multi-coated
Operating Temp,?F/?C	0 to 120/-17 to 49

EXPORT CONTROL NOTICE: This product is controlled for export and in-country transfer under the Export Administration Regulations (EAR). division contrary to U.S. law prohibited.

Features

Dot duplex reticle 56mm objective for enhanced low light performance. Red illuminated reticle.
Side focus adjustment for parallax removal. Single-piece, 30mm tube.
Aircraft grade aluminum. Hard anodized finish.
Capped turrets. Shockproof, fogproof, waterproof. Fully multi-coated optics.
