Sightmark Citadel 1-10x24 CR1 Riflescope
The Sightmark Citadel 1-10x24 CR1 riflescope (SM13138CR1) brings close- to mid-range shooters, hunters and law enforcement to the next level. The Citadel 1-10x24 CR1 riflescope comes feature packed with a fully multi-coated lens and fine-etched, red-illuminated reticle with 11 brightness settings. The riflescope includes a second focal-plane CR1 reticle, great for close- to mid-range shooting and quick target acquisition. The Citadel 1-10x24 comes complete with capped low-profile turrets, ½ MOA per click windage and elevation adjustments and BDC reticle calibrated for .223 55-grain ammunition. This riflescope is IP67-rated waterproof, shockproof and fogproof all while including a throw lever and flip-up caps.
Product Description
Product Downloads
Included in Package
- Flip up lens covers
- Throw lever attachment
- CR2032 battery
Batteries Used
- Type: CR2032
- Quantity: 1
Specifications
| Reticle, Type | CR1 |
|---|---|
| Reticle | Etched glass |
| Reticle, Color | Red |
| Illuminated (yes/no) | Yes |
| Relative Brightness | 0-11 |
| Magnification | 1-10 x |
| Diameter, Objective Lens | 24 mm |
| Diameter, Eyepiece | 1.6 / 40 in / mm |
| Diameter, Exit Pupil | 11.15 - 2.2 mm |
| Eye Relief | 3.7 3.1 / 93.98 - 78.74 in / mm |
| Field of view, m@100m | 36.76 - 3.6 |
| Field of view, ft@100yd | 110.3 - 10.8 |
| Diopter Adjustment | +2 to -2 |
| Diameter, Tube | 30 / 1.18 mm / in |
| Parallax Setting | 100 yds |
| MOA Adjustment | 1/2 MOA one click = |
| Windage Range of Adjustment | 100 MOA |
| Elevation Range of Adjustment | 100 MOA |
| Windage & Elevation, Lock | No |
| Maximum Recoil | 50 BMG |
| Battery Type | CR2032 |
| Battery life, hours | 70 - 100 |
| Battery Voltage, V | 3 |
| Sunshade | No |
| Nitrogen Filled | Yes |
| Shockproof | Yes |
| Fog Proof | Yes |
| Focal Plane | 2nd |
| IP Standard | IP67 - waterproof and dustproof |
| Body Material | Aluminum |
| Finish/Color | Matte Black |
| Lens Coating | Fully multi-coated |
| Operating Temperature | 0 to 120 / -17 to 49 F / C |
| Length | 11.26 / 286 in / mm |
| Width | 2.2 / 58 in / mm |
| Height (in/mm) | 1.7 / 42 in / mm |
| Weight, oz | 17.5 oz |
EXPORT CONTROL NOTICE: This product is controlled for export and in-country transfer under the Export Administration Regulations (EAR). division contrary to U.S. law prohibited.
Features
- BDC Reticle calibrated for .223 55-grain ammo; 10:1 zoom ratio;
- Capped low-profile turrets helps protect turrets and remain at zero; Second focal-plane reticle;
- Red-illuminated reticle with 11-brightness settings; Single piece 30mm tube; Aircraft-grade aluminum tube;
- Hard anodized finish; Shockproof / Fogproof / Waterproof; Fully multi-coated lens.
